Siemens CU230P-2 DP User Manual

List of Parameters
Parameters
1-381
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run sequence of instance NSW 0 within the run-time group set in p20221.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of input quantities X0 and X1 of instance NSW 1 of the numeric changeover switch.
Index: [0] = Input X0
[1] = Input X1
Description: Sets the signal source of the switch setting I of instance NSW 1 of the numeric changeover switch.
Description: Display parameter for output quantity Y of instance NSW 1 of the numeric changeover switch.
Description: Setting parameter for the run-time group in which the instance NSW 1 of the numeric changeover switch is to be
called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance NSW 1 within the run-time group set in p20226.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
p20222 NSW 0 run sequence / NSW 0 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 610
p20223[0...1] CI: NSW 1 inputs / NSW 1 inputs
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
p20224 BI: NSW 1 switch setting I / NSW 1 sw_setting
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
r20225 CO: NSW 1 output Y / NSW 1 output Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: PERCENT Data set: -
p20226 NSW 1 run-time group / NSW 1 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20227 NSW 1 run sequence / NSW 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 620
