Siemens CU230P-2 DP User Manual

Technology functions
Function diagrams
2-563
© Siemens AG 2009 All Rights Reserved SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Fig. 2-113 7975 – Bypass
- 7975 -
Function diagram
87654321
FP_7975_97_01.vsd
Technology functions
G120 CU230P-2
29.10.2009 V4.3
Bypass
SINAMICS
G120
CU230P-2
Interlock against
simultaneous closing
Bypass
contactors
Line
Relay outputs (digital outputs (DO))
Bypass config
0 ... 3
p1260 (0)
Switch t_monit
0 ... 5000 [ms]
p1274 (1000)
Bypass
configuration
Bypass STW / ZSW
r1261
r1261
n
t
p1264
0
1
0
1
p1263
0
1
p1262 p1262
t
t
t
r1261.0
r1261.1
"Fault present"
e.g. r0052.3
n_max +
2n_slip
f_line
n_set, inverter
n_motor
n_flying restart
.
.
.
