Siemens CU230P-2 DP - p1290[0...n] Vdc controller proportional gain (V;f); Vdc_ctrl Kp; p1291[0...n] Vdc controller integral time (V;f); Vdc_ctrl Tn; p1292[0...n] Vdc controller rate time (V;f); Vdc_ctrl t_rate; p1293[0...n] Vdc min controller output limit (V;f); Vdc_min outp_lim

Parameters
List of Parameters
1-168
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the proportional gain for the Vdc controller (DC link voltage controller).
Note: The gain factor is proportional to the capacitance of the DC link. The parameter is preset to a value that is optimally
adapted to the capacitance of the power unit.
Description: Sets the integral time for the Vdc controller (DC link voltage controller).
Description: Sets the rate time constant for the Vdc controller (DC link voltage controller).
Description: Sets the output limit for the Vdc min controller (DC link undervoltage controller).
Description: Activates/deactivates the automatic sensing of the switch-in level for the Vdc_max controller. When the sensing
function is deactivated, the activation threshold r1282 for the Vdc_max controller is determined from the parameter-
ized connection voltage p0210.
Value: 0: Automatic detection inhibited
1: Automatic detection enabled
Description: Sets the time threshold for the Vdc_min controller (kinetic buffering). If this value is exceeded a fault is output; the
required response can be parameterized.
Prerequisite: p1296 = 1.
Notice: If a time threshold has been parameterized, the Vdc_max controller should also be activated (p1280 = 3) so that the
drive does not shut down with overvoltage when Vdc_min control is exited (due to the time violation) and in the
event of fault response OFF3. It is also possible to increase the OFF3 ramp-down time p1135.
p1290[0...n] Vdc controller proportional gain (V/f) / Vdc_ctrl Kp
PM230
PM240
Access level: 3 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.00 100.00 1.00
p1291[0...n] Vdc controller integral time (V/f) / Vdc_ctrl Tn
PM230
PM240
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0 [ms] 10000 [ms] 40 [ms]
p1292[0...n] Vdc controller rate time (V/f) / Vdc_ctrl t_rate
PM230
PM240
Access level: 3 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0 [ms] 1000 [ms] 10 [ms]
p1293[0...n] Vdc min controller output limit (V/f) / Vdc_min outp_lim
PM240 Access level: 4 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.00 [Hz] 600.00 [Hz] 600.00 [Hz]
p1294 Vdc_max controller automatic detection ON signal level (V/f) / Vdc_max SenseOnLev
PM230
PM240
Access level: 3 Calculated: - Data type: Integer16
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0 1 0
p1295[0...n] Vdc_min controller time threshold (V/f) / Vdc_min t_thresh
PM240 Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Min Max Factory setting
0.000 [s] 10000.000 [s] 0.000 [s]
