Siemens CU230P-2 DP - p20137 AVA 1 run sequence; AVA 1 RunSeq; p20138 BI: MFP 0 input pulse I; MFP 0 inp_pulse I; p20139 MFP 0 pulse duration in ms; MFP 0 pulse_dur ms; r20140 BO: MFP 0 output Q; MFP 0 output Q

List of Parameters
Parameters
1-367
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run sequence of instance AVA 1 within the run-time group set in p20136.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source for the input pulse I of instance MFP 0 of the pulse generator.
Description: Setting parameter for pulse duration T in milliseconds of instance MFP 0 of the pulse generator.
Description: Display parameter for output pulse Q of instance MFP 0 of the pulse generator.
Description: Setting parameter for the run-time group in which the instance MFP 0 of the pulse generator is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance MFP 0 within the run-time group set in p20141.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source for the input pulse I of instance MFP 1 of the pulse generator.
p20137 AVA 1 run sequence / AVA 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 350
p20138 BI: MFP 0 input pulse I / MFP 0 inp_pulse I
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
p20139 MFP 0 pulse duration in ms / MFP 0 pulse_dur ms
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0.00 60000.00 0.00
r20140 BO: MFP 0 output Q / MFP 0 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20141 MFP 0 run-time group / MFP 0 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20142 MFP 0 run sequence / MFP 0 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 370
p20143 BI: MFP 1 input pulse I / MFP 1 inp_pulse I
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
