Parameters
List of Parameters
1-154
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Sets the start attempts of the automatic restart function for p1210 = 4, 6, 14, 16.
Dependency: Refer to: p1210, r1214
Refer to: F07320
Caution: A change is only accepted and made in the state "initialization" (r1214.0) and "wait for alarm" (r1214.1).
Notice: After fault F07320 occurs, the power-on command must be withdrawn and all of the faults acknowledged so that the
automatic restart function is reactivated.
After a complete blackout the start counter always starts with the counter value that applied before the blackout,
and decrements this startup attempt by 1. If a further attempt to acknolwedge is started by the automatic restart
function prior to blackout, e.g. when the CU remains active on blackout longer than the time p1212 / 2, the fault
counter will already have been decremented by 1. In this case, the fault counter is thus decreased by the value 2.
Note: A start attempt starts immediately when a fault occurs. The start attempt is considered to been completed if the
motor was magnetized (r0056.4 = 1) and an additional delay time of 1 s has expired.
As long as a fault is present, an acknowledge command is generated in the time intervals of p1212 / 2. When suc-
cessfully acknowledged, the start counter is decremented. If, after this, a fault re-occurs before a restart has been
completed, then acknowledgement starts again from the beginning.
Fault F07320 is output if, after several faults occur, the number of parameterized start attempts has been reached.
After a successful start attempt, i.e. a fault/error has no longer occurred up to the end of the magnetizing phase, the
start counter is again reset to the parameter value after 1 s. If a fault re-occurs - the parameterized number of start
attempts is again available.
At least one start attempt is always carried out.
After a line supply failure, acknowledgement is immediate and when the line supply returns, the system is powered
up. If, between successfully acknowledging the line fault and the line supply returning, another fault occurs, then its
acknowledgement also causes the start counter to be decremented.
Description: Sets the delay time up to restart.
Dependency: This parameter setting is active for p1210 = 4, 6.
For p1210 = 1, the following applies: Faults are only automatically acknowledged in half of the waiting time, no
restart.
Refer to: p1210, r1214
Caution: A change is only accepted and made in the state "initialization" (r1214.0) and "wait for alarm" (r1214.1).
Note: The faults are automatically acknowledged after half of the waiting time has expired and the full waiting time.
If the cause of a fault is not removed in the first half of the delay time, then it is no longer possible to acknowledge in
the waiting time.
p1211 Automatic restart, start attempts / AR start attempts
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0 10 3
p1212 Automatic restart, delay time start attempts / AR t_wait start
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Min Max Factory setting
0.1 [s] 1000.0 [s] 1.0 [s]
