Parameters

List of Parameters

1-242

SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009

Description: Setting to invert the individual binector inputs of the binector connector converter.

Index: [0] = Status word 1

[1] = Status word 2

[2] = Free status word 3

[3] = Free status word 4

[4] = Free status word 5

Dependency: Refer to: p2080, p2081, p2082, p2083, r2089

Description: Connector output to interconnect the status words to a PZD send word.

Index: [0] = Status word 1

[1] = Status word 2

[2] = Free status word 3

[3] = Free status word 4

[4] = Free status word 5

Dependency: Refer to: p2051, p2080, p2081, p2082, p2083

Note: r2089 together with p2080 to p2084 forms five binector-connector converters.

p2088[0...4] Invert binector-connector converter status word / Bin/con ZSW inv

CU230P-2 DP Access level: 3 Calculated: - Data type: Unsigned16

Can be changed: U, T Scaling: - Data set: -

Min Max Factory setting

- - 1010 1000 0000 0000 bin

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 Inverted Not inverted -

01 Bit 1 Inverted Not inverted -

02 Bit 2 Inverted Not inverted -

03 Bit 3 Inverted Not inverted -

04 Bit 4 Inverted Not inverted -

05 Bit 5 Inverted Not inverted -

06 Bit 6 Inverted Not inverted -

07 Bit 7 Inverted Not inverted -

08 Bit 8 Inverted Not inverted -

09 Bit 9 Inverted Not inverted -

10 Bit 10 Inverted Not inverted -

11 Bit 11 Inverted Not inverted -

12 Bit 12 Inverted Not inverted -

13 Bit 13 Inverted Not inverted -

14 Bit 14 Inverted Not inverted -

15 Bit 15 Inverted Not inverted -

r2089[0...4] CO: Send binector-connector converter status word / Bin/con ZSW send

Access level: 3 Calculated: - Data type: Unsigned16

Unit: - Scaling: - Data set: -

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 On Off -

01 Bit 1 On Off -

02 Bit 2 On Off -

03 Bit 3 On Off -

04 Bit 4 On Off -

05 Bit 5 On Off -

06 Bit 6 On Off -

07 Bit 7 On Off -

08 Bit 8 On Off -

09 Bit 9 On Off -

10 Bit 10 On Off -

11 Bit 11 On Off -

12 Bit 12 On Off -

13 Bit 13 On Off -

14 Bit 14 On Off -

15 Bit 15 On Off -
