Siemens CU230P-2 DP User Manual

Function diagrams Internal control/status words 2-492
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Fig. 2-47 2512 – Control word 1 (r0054)
- 2512 -
Function diagram
87654321
FP_2512_97_51.vsd
Internal control/status words
G120 CU230P-2
29.10.2009 V4.3
Control word 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
Sequence control
Setpoint channel
Setpoint channel
Setpoint channel
Setpoint channel
Sequence control
Setpoint channel
Sequence control
Sequence control
Setpoint channel
Setpoint channel
Setpoint channel
Sequence control
Sequence control
Setpoint channel
Sequence control
Sequence control
Setpoint channel
All bits = 1 -->
drive runs
Bit 10 in STW1 must be set to
ensure that the drive accepts the
process data.
Bit No. Control word 1 (r0054)
0 = OFF1, Shutdown via ramp, followed by pulse disable
1 = ON, operating condition (edge-controlled)
0 = OFF2: Electrical stop, pulse disable, motor coasts down
1 = Operating condition
0 = OFF3: Fast stop
1 = Operating condition
1 = Operation enable
1 = Ramp-function generator enable
1 = Continue ramp-function generator
1 = Speed setpoint enable
1 = Acknowledge fault
1 = Jog bit 0
1 = Jog bit 1
1 = Master ctrl by PLC
1 = Directions reversal (setpoint)
Reserved
1 = Motorized potentiometer raise
1 = Motorized potentiometer lower
1 = CDS bit 0
STW 1
r0054
r0054
STW seq_ctrl
r0898
r0898
.0
[2501.7]
[2501.7]
[2501.7]
[2501.7]
[2501.7]
[2501.7]
[2501.7]
[2546.7]
[2501.7]
[2501.7]
[2501.7]
[2505.7]
[2505.7]
[2505.7]
[8560.7]
(1)
1. OFF2
p0844 [C]
(1)
2. OFF2
p0845 [C]
(1)
1. OFF3
p0848 [C]
(1)
2. OFF3
p0849 [C]
(1)
n_set enable
p1142 [C]
(722.0)
ON/OFF1
p0840 [C]
(1)
Operation enable
p0852 [C]
(1)
RFG enable
p1140 [C]
(1)
Continue RFG
p1141 [C]
(1)
Master ctrl by PLC
p0854 [C]
(0)
Jog bit 0
p1055 [C]
(0)
Jog bit 1
p1056 [C]
r0898.1
r0898
r0898.2
r0898
r0898.3
r0898
r0898.4
r0898
r0898.5
r0898
r0898.6
r0898
r2138.7
r2138
r0898.8
r0898
r0898.9
r0898
r0898.10
r0898
r1198.11
r1198
r1198.13
r1198
r1198.14
r1198
r0836.0
r0836
(0)
Mop raise
p1035 [C]
(0)
Mop lower
p1036 [C]
(722.1)
Setp inv
p1113 [C]
Pulse generator
(0)
1. Acknowledge
p2103 [C]
(722.2)
2. Acknowledge
p2104 [C]
(0)
3. Acknowledge
p2105 [C]
