Siemens CU230P-2 DP - r0203[0...n] Actual power unit type; PU actual type; r0204[0...n] Power unit hardware properties; PU HW property; p0205 Power unit application; PU application

List of Parameters
Parameters
1-37
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the type of power unit found.
Value: 2: MICROMASTER 440
3: MICROMASTER 411
4: MICROMASTER 410
5: MICROMASTER 436
6: MICROMASTER 440 PX
7: MICROMASTER 430
100: SINAMICS S
101: SINAMICS S (value)
102: SINAMICS S (combi)
112: PM220 (SINAMICS G120)
113: PM230 (SINAMICS G120)
114: PM240 (SINAMICS G120)
115: PM250 (SINAMICS G120)
116: PM260 (SINAMICS G120)
118: SINAMICS G120 Px
120: PM340 (SINAMICS S120)
150: SINAMICS G
200: SINAMICS GM
250: SINAMICS SM
260: SINAMICS SM120
300: SINAMICS GL
350: SINAMICS SL
400: SINAMICS DCM
Note: For parallel circuit configurations, the parameter index is assigned to a power unit.
Description: Displays the properties supported by the power unit hardware.
Description: The duty cycles can be overloaded provided that the drive converter is operated with its base load current before
and after the overload. This is based on a load duty cycle of 300 s.
Value: 0: Load duty cycle with high overload for vector drives
1: Load duty cycle with low overload for vector drives
Notice: The parameter value is not reset when the factory setting is restored (see p0010 = 30, p0970).
Note: When the parameter is changed, all of the motor parameters, the technological application and the control mode
are pre-assigned according to the selected application. The parameter has not influence when calculating the ther-
mal overload.
p0205 can only be changed to the settings that are saved in the power unit EEPROM.
r0203[0...n] Actual power unit type / PU actual type
Access level: 3 Calculated: - Data type: Integer16
Unit: - Scaling: - Data set: PDS
r0204[0...n] Power unit hardware properties / PU HW property
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: PDS
Bit field: Bit Signal name 1 signal 0 signal FP
01 RFI filter available Yes No -
07 F3E regenerative feedback into the line sup-
ply
Yes No -
08 Internal Braking Module Yes No -
12 Safe Brake Control (SBC) supported No Yes -
14 Internal LC output filter Yes No -
p0205 Power unit application / PU application
PM230 Access level: 1 Calculated: - Data type: Integer16
Can be changed: C(1, 2) Scaling: - Data set: -
Min Max Factory setting
0 1 1
