Parameters
List of Parameters
1-236
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Displays the PZD (actual values) with word format sent to the fieldbus master.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
Description: Status display for the PROFIBUS interface.
Value: 0: Off
1: No connection (search for baud rate)
2: Connection OK (baud rate found)
3: Cyclic connection with master (data exchange)
4: Cyclic data OK
Note: Re r2054 = 3:
In state 3 (the LED flashes green), a cyclic connection has been established with the PROFIBUS master, but the
following condition for cyclic operation has not been fulfilled:
- No setpoints are being received as the PROFIBUS master is in the STOP condition.
Re r2054 = 4:
In the status 4 (LED green), the cyclic connection to the PROFIBUS master has been established and setpoints are
being received.
Description: Diagnostics display for the PROFIBUS interface.
Index: [0] = Master bus address
[1] = Master input total length bytes
[2] = Master output total length bytes
r2053[0...7] PROFIdrive diagnostics send PZD word / Diag send word
Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Bit 0 On Off -
01 Bit 1 On Off -
02 Bit 2 On Off -
03 Bit 3 On Off -
04 Bit 4 On Off -
05 Bit 5 On Off -
06 Bit 6 On Off -
07 Bit 7 On Off -
08 Bit 8 On Off -
09 Bit 9 On Off -
10 Bit 10 On Off -
11 Bit 11 On Off -
12 Bit 12 On Off -
13 Bit 13 On Off -
14 Bit 14 On Off -
15 Bit 15 On Off -
r2054 PROFIBUS status / PB status
CU230P-2 DP Access level: 3 Calculated: - Data type: Integer16
Unit: - Scaling: - Data set: -
r2055[0...2] PROFIBUS diagnostics standard / PB diag standard
CU230P-2 DP Access level: 3 Calculated: - Data type: Unsigned16
Unit: - Scaling: - Data set: -
