Page #383 background image
List of Parameters
Parameters
1-383
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for the run sequence of instance LIM 0 within the run-time group set in p20234.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of input quantity X of instance LIM 1 of the limiter.
Description: Setting parameter for the upper limit value LU of instance LIM 1 of the limiter.
Description: Setting parameter for the lower limit value LL of instance LIM 1 of the limiter.
Description: Display parameter for the limited output quantity Y of instance LIM 1 of the limiter.
Description: Display parameter of instance LIM 1 of limiter QU (upper limit reached), i.e. QU = 1 for X >= LU.
Description: Display parameter of instance LIM 1 of limiter QL (lower limit reached), i.e. QL = 1 for X <= LL.
p20235 LIM 0 run sequence / LIM 0 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 640
p20236 CI: LIM 1 input X / LIM 1 input X
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Min Max Factory setting
- - 0
p20237 LIM 1 upper limit value LU / LIM 1 upper lim LU
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.0000
p20238 LIM 1 lower limit value LL / LIM 1 lower lim LL
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.0000
r20239 CO: LIM 1 output Y / LIM 1 output Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Unit: - Scaling: PERCENT Data set: -
r20240 BO: LIM 1 input quantity at the upper limit QU / LIM 1 QU
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
r20241 BO: LIM 1 input quantity at the lower limit QL / LIM 1 QL
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
