List of Parameters
Parameters
1-371
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
Description: Setting parameter for pulse delay time T in milliseconds of instance PDE 1 of the closing delay device.
Description: Display parameter for output pulse Q of instance PDE 1 of the closing delay device.
Description: Setting parameter for the run-time group in which instance PDE 1 of the closing delay device is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance PDE 1 within the run-time group set in p20166.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source for the input pulse I of instance PDF 0 of the breaking delay device.
Description: Setting parameter for pulse extension time T in milliseconds of instance PDF 0 of the breaking delay device.
Description: Display parameter for output pulse Q of instance PDF 0 of the breaking delay device.
p20164 PDE 1 pulse delay time in ms / PDE 1 t_del ms
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0.00 60000.00 0.00
r20165 BO: PDE 1 output Q / PDE 1 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
p20166 PDE 1 run-time group / PDE 1 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
5 9999 9999
p20167 PDE 1 run sequence / PDE 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0 32000 440
p20168 BI: PDF 0 input pulse I / PDF 0 inp_pulse I
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
- - 0
p20169 PDF 0 pulse extension time in ms / PDF 0 t_ext ms
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Min Max Factory setting
0.00 60000.00 0.00
r20170 BO: PDF 0 output Q / PDF 0 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Unit: - Scaling: - Data set: -
