Function diagrams
Free Function Blocks
2-538
© Siemens AG 2009 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 11/2009
2.10 Free Function Blocks
Function diagrams
7210 – AND (AND function block with 4 inputs) 2-539
7212 – OR (OR function block with 4 inputs) 2-540
7214 – XOR (XOR function block with 4 inputs) 2-541
7216 – NOT (inverter) 2-542
7220 – ADD (adder with 4 inputs), SUB (subtracter) 2-543
7222 – MUL (multiplier), DIV (divider) 2-544
7224 – AVA (absolute value generators) 2-545
7225 – NCM (numerical comparator) 2-546
7226 – PLI20 (scaling polyline) 2-547
7230 – MFP (pulse generator), PCL (pulse shortener) 2-548
7232 – PDE (switch-in delay) 2-549
7233 – PDF (switch-out delay) 2-550
7234 – PST (pulse extender) 2-551
7240 – RSR (RS flipflop), DFR (D flipflop) 2-552
7250 – BSW (binary changeover switch), NSW (numerical changeover switch) 2-553
7260 – LIM (limiter) 2-554
7262 – PT1 (smoothing element) 2-555
7264 – INT (integrator), DIF (differentiating element) 2-556
7270 – LVM (limit value monitor) 2-557
