5. PARAMETERS
5 - 43
No./symbol/
name
Setting
digit
Function
Initial
value
[unit]
Control
mode
P
S
T
PC15
MOD2
Analog
monitor 2
output
_ _ x x
Analog monitor 2 output selection
Select a signal to output to MO2 (Analog monitor 2). Refer to app. 7.3 for detection
point of output selection.
Refer to [Pr. PC14] for settings.
01h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PC16
MBR
Electromagnetic
brake sequence
output
Set the delay time between MBR (Electromagnetic brake interlock) and the base
drive circuit is shut-off. For the timing chart of when the servo motor with an
electromagnetic brake is used, refer to section 3.10.2.
Setting range: 0 to 1000
0
[ms]
PC17
ZSP
Zero speed
Set the output range of ZSP (Zero speed detection).
ZSP (Zero speed detection) has hysteresis of 20 r/min or 20 mm/s.
Setting range: 0 to 10000
50
[r/min]/
[mm/s]
PC18
*BPS
Alarm history
clear
_ _ _ x
Alarm history clear selection
Clear the alarm history.
0: Disabled
1: Enabled
When "Enabled" is set, the alarm history will be cleared at the next power-on. Once
the alarm history is cleared, the setting becomes disabled automatically.
0h
_ _ x _
For manufacturer setting
0h
_ x _ _
0h
x _ _ _
0h
