SMC Networks LECSB2-T Series User Manual

8. TROUBLESHOOTING
8 - 71
(3)
The cam control
command was turned
on during servo motor
driving, and the servo
motor stopped.
Check if the cam
control
command was turned
on while the travel
completion was on.
The cam control
command was not
turned on while the
travel completion was
on.
Turn on the cam control
command while the
travel completion was on.
The cam control
command was turned
on while the travel
completion was on.
Check (4).
(4)
The cam control
command was turned
on at the time of
incompletion of home
position return.
Check if the home
position return
completion is on.
The home position
return completion is
off.
Make a home position
return, and turn on the
cam control command.
The home position
return completion is
on.
Check (5).
(5)
It became servo-off
during cam control.
Check if it is servo-
off.
It is servo-off.
After servo-on, turn on
the cam control command
again.
It is servo-on.
Check (6).
(6)
A home position is
erased during cam
control.
Check if the home
position return
completion is off.
The home position
return
completion is off.
After the home position
return completion, turn
on the cam control
command again.
The home position
return completion is
on.
Check (7).
(7)
It is stopped at a
software limit during
cam control.
Check if a software
limit is reached.
A software limit is
reached.
After it is retracted from the
position of a software limit,
turn on the cam control
command again.
A software limit is not
reached.
Check (8).
(8)
It is stopped at a stroke
limit during cam control.
Check if a stroke limit
is reached.
A stroke limit is
reached.
After it is retracted from the
position of a stroke limit, turn
on the cam control command
again.
