16 - 27
16. POSITIONING MODE
Device
Symbol
Connector
pin No.
Function and application
I/O
divisi
on
Control
mode
CP
CL
PS
Analog override
selection
OVR
Turning on OVR will enable VC (Analog override).
DI-1
Teach
TCH
Use this for teaching. Turning on TCH in the point table method will rewrite
a position data of the selected point table No. to the current position.
DI-1
Program input 1
PI1
Turning on PI1 will restart a step which was suspended with the SYNC (1)
command during programming.
DI-1
Program input 2
PI2
Turning on PI2 will restart a step which was suspended with the SYNC (2)
command during programming.
DI-1
Program input 3
PI3
Turning on PI3 will restart a step which was suspended with the SYNC (3)
command during programming.
DI-1
Current position
latch input
LPS
Turning on LPS during execution of the LPOS command will latch a current
position with its rising edge. The latched current position can be read with
communication commands.
DI-1
