16 - 45
16. POSITIONING MODE
Note 1.
Output signals are not assigned by default. Assign the output signals with [Pr. PD47] as necessary.
3.
This diagram shows sink I/O interface. For source I/O interface, refer to section 3.9.3.
4.
The illustration of the 24 V DC power supply is divided between input signal and output signal for convenience. However, they
can be configured by one.
5.
Do not use it.
