SMC Networks LECSB2-T Series User Manual

16 - 85
16. POSITIONING MODE
3) Position data unit ([Pr. PT01])
Set the unit of the position data.
[Pr. PT01] setting
Position data unit
_ 0 _ _
mm
_ 1 _ _
inch
_ 2 _ _
degree
_ 3 _ _
pulse
4) Feed length multiplication ([Pr. PT03])
Set the feed length multiplication (STM) of the position data.
[Pr. PT03] setting
Position data input range
[mm]
[inch]
[degree] (Note 1)
[pulse] (Note 1)
_ _ _ 0
- 999.999 to + 999.999
- 99.9999 to + 99.9999
_ _ _ 1
- 9999.99 to + 9999.99
- 999.999 to + 999.999
- 360.000 to + 360.000
(Note 2)
- 999999 to + 999999
_ _ _ 2
- 99999.9 to + 99999.9
- 9999.99 to + 9999.99
_ _ _ 3
- 999999 to + 999999
- 99999.9 to + 99999.9
Note
1.
The feed length multiplication setting ([Pr. PT03]) is not applied to the unit multiplication factor.
Adjust the unit multiplication factor in the electronic gear setting ([Pr. PA06] and [Pr. PA07]).
2.
The "-" sign has different meanings under the absolute value command method and the incremental value command method.
Refer to section 4.2.1 for details.
(c) Operation
Selecting DI0 to DI7 for the point table and switching on ST1 starts positioning to the position data at
the set speed, acceleration time constant and deceleration time constant. At this time, ST2 (Reverse
rotation start) is invalid.
Item
Used device
Description
Automatic operation mode
selection
MD0 (Operation mode selection 1)
Switch on MD0.
Point table selection
DI0 (Point table No. selection 1)
DI1 (Point table No. selection 2)
DI2 (Point table No. selection 3)
DI3 (Point table No. selection 4)
DI4 (Point table No. selection 5)
DI5 (Point table No. selection 6)
DI6 (Point table No. selection 7)
DI7 (Point table No. selection 8)
Refer to (2) (b) of 4.2.1.
Start
ST1 (Forward rotation start)
Switch on ST1 to start.
