SMC Networks LECSB2-T Series User Manual

16 - 224
16. POSITIONING MODE
(4) Timing chart
The following timing chart shows that a JOG operation is performed at a stop of the station No. 0 when
servo-on.
Note 1.
When the rest of command travel distance is other than "0", ST1 (Forward rotation start) will not be accepted. Refer to section
6.4.5 (1).
2.
SIG and RT (Second acceleration/deceleration selection) will not be accepted during operation. Selection of the servo motor
speed and acceleration/deceleration time constants will be enabled by on-edge of ST1 (Forward rotation start). However,
when the rest of command travel distance is other than "0", turning on ST1 (Forward rotation start) will not be enabled.
3.
Counting will start when the rest of command travel distance becomes "0".
4.
When MEND (Travel completion) is off, the station position outputs will be "0" (all off).
Power supply
ON
OFF
ON
OFF
ON
OFF
ALM (Malfunction)
MEND (Travel completion)
PS0 (Station output 1) to
PS7 (Station output 8)
(Note 5)
Current station position
Servo motor speed
ON
OFF
ST1 (Forward rotation start)
ON
OFF
SIG (External limit/Rotation direction
decision/Automatic speed selection)
ON
OFF
RT (Second acceleration/deceleration
selection)
ON
OFF
MD0 (Operation mode selection 1)
ON
OFF
MD1 (Operation mode selection 2)
Torque limit
5 ms or
longer
Torque limit value of
[Pr. PA11] and [Pr. PA12]
Torque limit value of
[Pr. PA11] and [Pr. PA12]
Torque limit value
of [Pr. PC35]
Torque limit value
of [Pr. PC35]
Torque limit value
of [Pr. PC35]
Torque limit value of
[Pr. PA11] and [Pr. PA12]
All off (Note 4) All off (Note 4) All off (Note 4)
Station
output 1
Number of stations: 8
5 ms or
longer
[Pr. PC31]
setting time
[Pr. PT39] setting time (Note 3)
Manual operation
speed 2
[Pr. PC02]
setting time
Manual operation
speed 1
[Pr. PC01]
setting time
Manual
operation
speed 1
5 ms or longer
Ignored
(Note 2)
2
1
0
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
7
6
5
4
3
1 2 3 3 4 5 60 7 7 6 5 4
Station output 3Station output 1
[Pr. PC30]
setting time
Ignored (Note 1)
Ignored (Note 2)
Forward rotation
0 r/min
Reverse rotation
