SMC Networks LECSB2-T Series User Manual

16 - 286
16. POSITIONING MODE
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control mode
CP
CL
PS
PD06
*DI2H
Input device
selection 2H
Any input device can be assigned to the CN1-16 pin.
_ _ x x
Not used with the positioning mode.
21h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for settings.
20h
PD08
*DI3H
Input device
selection 3H
Any input device can be assigned to the CN1-17 pin.
_ _ x x
Not used with the positioning mode.
07h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for settings.
07h
PD10
*DI4H
Input device
selection 4H
Any input device can be assigned to the CN1-18 pin.
_ _ x x
Not used with the positioning mode.
08h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for settings.
08h
PD12
*DI5H
Input device
selection 5H
Any input device can be assigned to the CN1-19 pin.
_ _ x x
Not used with the positioning mode.
03h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for settings.
38h
PD14
*DI6H
Input device
selection 6H
Any input device can be assigned to the CN1-41 pin.
_ _ x x
Not used with the positioning mode.
20h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for settings.
39h
PD18
*DI8H
Input device
selection 8H
Any input device can be assigned to the CN1-43 pin.
_ _ x x
Not used with the positioning mode.
00h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for settings.
0Ah
PD20
*DI9H
Input device
selection 9H
Any input device can be assigned to the CN1-44 pin.
_ _ x x
Not used with the positioning mode.
00h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for settings.
0Bh
PD22
*DI10H
Input device
selection 10H
Any input device can be assigned to the CN1-45 pin.
_ _ x x
Not used with the positioning mode.
23h
x x _ _
Positioning mode - Device selection
Refer to table 7.10 in [Pr. PD04] for settings.
2Bh
