16. POSITIONING MODE
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control mode
CP
CL
PS
PD23
*DO1
Output device
selection 1
_ _ x x
Device selection
Any output device can be assigned to the CN1-22 pin.
Refer to table 7.11 for settings.
04h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
Table 7.11 Selectable output devices
Setting
value
Output device
CP
CL
PS
_ _ 0 0
Always off
Always off
Always off
_ _ 0 2
RD
RD
RD
_ _ 0 3
ALM
ALM
ALM
_ _ 0 4
INP
INP
INP
_ _ 0 5
MBR
MBR
MBR
_ _ 0 6
DB
DB
DB
_ _ 0 7
TLC
TLC
TLC
_ _ 0 8
WNG
WNG
WNG
_ _ 0 9
BWNG
BWNG
BWNG
_ _ 0 A
SA
SA
Always off
_ _ 0 B
Always off
Always off
Always off
_ _ 0 C
ZSP
ZSP
ZSP
_ _ 0 D
MTTR
MTTR
MTTR
_ _ 0 F
CDPS
CDPS
CDPS
_ _ 1 0
CLDS
CLDS
CLDS
_ _ 1 1
ABSV
ABSV
ABSV
_ _ 1 F
CPCC
CPCC
_ _ 2 3
CPO
CPO
CPO
_ _ 2 4
ZP
ZP
ZP
_ _ 2 5
POT
POT
Always off
_ _ 2 6
PUS
PUS
Always off
_ _ 2 7
MEND
MEND
MEND
_ _ 2 9
CLTS
CLTS
_ _ 2 B
CLTSM
CLTSM
_ _ 2 C
PED
PED
_ _ 2 D
SOUT
_ _ 2 E
OUT1
_ _ 2 F
OUT2
_ _ 3 0
OUT3
_ _ 3 1
ALMWNG
ALMWNG
ALMWNG
_ _ 3 2
BW9F
BW9F
BW9F
_ _ 3 3
MSDH
MSDH
_ _ 3 4
MSDL
MSDL
_ _ 3 7
CAMS
CAMS
