16. POSITIONING MODE
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control mode
CP
CL
PS
PD23
*DO1
Output device
selection 1
Setting
value
Output device (Note 1)
CP
CL
PS
_ _ 3 8
PT0
PS0
_ _ 3 9
PT1
PS1
_ _ 3 A
PT2
PS2
_ _ 3 B
PT3
PS3
_ _ 3 C
PT4
PS4
_ _ 3 D
PT5
PS5
_ _ 3 E
PT6
PS6
_ _ 3 F
PT7
PS7
Note 1.
CP: Positioning mode (point table method)
CL: Positioning mode (program method)
PS: Positioning mode (indexer method)
The diagonal lines indicate manufacturer settings. Never change the setting.
PD24
*DO2
Output device
selection 2
_ _ x x
Device selection
Any output device can be assigned to the CN1-23 pin.
Refer to table 7.11 in [Pr. PD23] for settings.
0Ch
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PD25
*DO3
Output device
selection 3
_ _ x x
Device selection
Any output device can be assigned to the CN1-24 pin.
Refer to table 7.11 in [Pr. PD23] for settings.
04h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PD26
*DO4
Output device
selection 4
_ _ x x
Device selection
Any output device can be assigned to the CN1-25 pin.
Refer to table 7.11 in [Pr. PD23] for settings.
07h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PD28
*DO6
Output device
selection 6
_ _ x x
Device selection
Any output device can be assigned to the CN1-49 pin.
Refer to table 7.11 in [Pr. PD23] for settings.
02h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PD29
*DIF
Input filter
setting
Select a filter for the input signal.
_ _ _ x
Input signal filter selection
If external input signal causes chattering due to noise, etc., input filter is used to
suppress it.
0: None
1: 0.888 [ms]
2: 1.777 [ms]
3: 2.666 [ms]
4: 3.555 [ms]
5: 4.444 [ms]
6: 5.333 [ms]
4h
_ _ x _
RES (Reset) dedicated filter selection
0: Disabled
1: Enabled (50 [ms])
0h
_ x _ _
CR (Clear) dedicated filter selection
0: Disabled
1: Enabled (50 [ms])
0h
x _ _ _
For manufacturer setting
0h
