SMC Networks LECSB2-T Series User Manual

16 - 306
16. POSITIONING MODE
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control mode
CP
CL
PS
PT42
*OVM
Digital
override
minimum
multiplication
Set a minimum speed for when the digital override function is enabled.
When you use the digital override function, multiplication can be set with [Pr. PT42]
and [Pr. PT43]. Set this and [Pr. PT43] at a time.
Refer to the following table for how to calculate multiplication value.
Setting "0" will be recognized as "1".
Setting range: 0 to 100
0
[%]
(Note) Input device
Multiplication [%]
OV3
OV2
OV1
OV0
0
0
0
0
Fixed to 100
0
0
0
1
[Pr. PT42]
0
0
1
0
[Pr. PT42] + [Pr. PT43] × 1
0
0
1
1
[Pr. PT42] + [Pr. PT43] × 2
0
1
0
0
[Pr. PT42] + [Pr. PT43] × 3
0
1
0
1
[Pr. PT42] + [Pr. PT43] × 4
0
1
1
0
[Pr. PT42] + [Pr. PT43] × 5
0
1
1
1
[Pr. PT42] + [Pr. PT43] × 6
1
0
0
0
[Pr. PT42] + [Pr. PT43] × 7
1
0
0
1
[Pr. PT42] + [Pr. PT43] × 8
1
0
1
0
[Pr. PT42] + [Pr. PT43] × 9
1
0
1
1
[Pr. PT42] + [Pr. PT43] × 10
1
1
0
0
[Pr. PT42] + [Pr. PT43] × 11
1
1
0
1
[Pr. PT42] + [Pr. PT43] × 12
1
1
1
0
[Pr. PT42] + [Pr. PT43] × 13
1
1
1
1
Fixed to 0
Note.
0: Off
1: On
PT43
*OVS
Digital
override pitch
width
Set an override pitch width for when the digital override function is enabled.
When you use the digital override function, multiplication can be set with [Pr. PT42]
and [Pr. PT43]. Set this and [Pr. PT42] at a time.
Refer to the table of [Pr. PT42] for settings.
Setting "0" will be recognized as "1".
Setting range: 0 to 20
0
[%]
