16. POSITIONING MODE
(13) Others (command [0] [0], [0] [2])
Command
Data No.
Description
Control
mode
Frame
length
CP/
CL
PS
[0] [0]
[1] [2]
Reading test operation mode
0000: Normal mode (not test operation mode)
0001: JOG operation
0002: Positioning operation
0004: Output signal (DO) forced output
0005: Single-step feed operation
(No
te)
4
[1] [D]
Reading EEP-ROM stored data type
0000: Initial state
0001: Point table method
0002: Program method
[1] [E]
Reading control mode
0006: Positioning mode (point table method)
0007: Positioning mode (program method)
0008: Positioning mode (indexer method)
[0] [2]
[9] [0]
Servo motor-side pulse unit absolute position
8
[9] [1]
Command unit absolute position
[7] [0]
Software version
16
Note.
"0005 (single-step feed operation)" is not available in the indexer method.
