16. POSITIONING MODE
(5) Current alarm (command [8] [2])
Command
Data No.
Description
Setting range
Control
mode
Frame
length
CP
CL
PS
[8] [2]
[0] [0]
Alarm clear
1EA5
4
(6) I/O device prohibition (command [9] [0])
Command
Data No.
Description
Setting range
Control
mode
Frame
length
CP
CL
PS
[9] [0]
[0] [0]
Turns off the input device, external analog input signal, and
pulse train input, except EM2, LSP and LSN, independently of
the external on/off statuses.
1EA5
4
[0] [3]
Prohibits all output devices (DO).
1EA5
[1] [0]
Cancels the prohibition of the input device, external analog
input signal and pulse train input, except EM2, LSP and LSN.
1EA5
[1] [3]
Cancels the prohibition of the output device.
1EA5
(7) Operation mode selection (command [8] [B])
Command
Data No.
Description
Setting range
Control
mode
Frame
length
CP
CL
PS
[8] [B]
[0] [0]
Selection of test operation mode
0000: Test operation mode cancel
0001: JOG operation
0002: Positioning operation
0004: Output signal (DO) forced output
0005: Single-step feed operation
0000 to 0002,
0004, 0005
(No
te)
4
Note.
"0005 (single-step feed operation)" is not available in the indexer method.
(8) Test operation mode data (command [9] [2], [A] [0])
Command
Data No.
Description
Setting range
Control
mode
Frame
length
CP
CL
PS
[9] [2]
[0] [0] to [0] [2]
Input signal for test operation
(Refer to
section
14.5.7 .)
8
[A] [0]
Forced output of signal pin
(Refer to
section 14.5.9.)
