Writes the servo motor speed in the test operation mode
(JOG operation and positioning operation).
Writes the acceleration/deceleration time constant in the test
operation mode (JOG operation and positioning operation).
Set the travel distance of the test operation mode (positioning
operation).
Select the positioning direction of the test operation
(positioning operation).
This is a start command of the test operation (positioning
operation).
This is used to make a temporary stop during test operation
(positioning operation). "□" in the data indicates a blank.
STOP: Temporary stop
GO□□: Restart for remaining distance
CLR□: Remaining distance clear
(9) Point table setting data (command [C] [0], [C] [2], [C] [6], [C] [7], [C] [8], [C] [A], [C] [B])
Writing position data of each point table
The decimal equivalent of the data No. value (hexadecimal)
corresponds to the point table No.
Writing M code of each point table
The decimal equivalent of the data No. value (hexadecimal)
corresponds to the point table No.
Writing speed data of each point table
The decimal equivalent of the data No. value (hexadecimal)
corresponds to the point table No.
Writing acceleration time constant of each point table
The decimal equivalent of the data No. value (hexadecimal)
corresponds to the point table No.
Writing deceleration time constant of each point table
The decimal equivalent of the data No. value (hexadecimal)
corresponds to the point table No.
Writing dwell of each point table
The decimal equivalent of the data No. value (hexadecimal)
corresponds to the point table No.
Writing auxiliary function of each point table
The decimal equivalent of the data No. value (hexadecimal)
corresponds to the point table No.
0: Forward rotation direction
1: Reverse rotation direction
0: Command pulse unit
1: Encoder pulse unit
0 0
