16 - 346
16. POSITIONING MODE
(f) Auxiliary function
Writes auxiliary function of point tables.
Transmits the command [C] [B] + the data No. [0] [1] to [F] [F] corresponding to the point tables to
write + data. Refer to section 10.1.1.
Command
Data No.
Data
[C] [B]
[0] [1] to [F] [F]
Refer to the following
diagram.
When the auxiliary function is changed frequently using communication, set "1" to the mode to
change only the RAM data in the driver.
When changing data once or more within an hour, do not write it to the EEP-ROM.
(g) M code
Writes M code of point tables.
Transmits the command [C] [2] + the data No. [0] [1] to [F] [F] corresponding to the point tables to
write + data. Refer to section 10.1.1.
Command
Data No.
Data
[C] [2]
[0] [1] to [F] [F]
Refer to the following
diagram.
When the M code is changed frequently using communication, set "1" to the mode to change only
the RAM data in the driver.
When changing data once or more within an hour, do not write it to the EEP-ROM.
Hexadecimal
Writing mode
0: Writing to EEP-ROM/RAM
1: Writing to RAM
0
Hexadecimal
Writing mode
0: Writing to EEP-ROM/RAM
1: Writing to RAM
0
