SMC Networks LECSB2-T Series User Manual

APPENDIX
App. - 20
Setting
value
Output item
Description
Setting
value
Output item
Description
0C
Feedback position
(Note 1, 2, 3)
(±10 V/100 Mpulse)
100 M [pulse]
CW direction
CCW direction
100 M [pulse]
0
10 [V]
-10 [V]
0D
Bus voltage
400 [V]
0
8 [V]
0E
Speed command 2
(Note 3)
Maximum speed
CW direction
CCW direction
Maximum speed
0
8 [V]
-8 [V]
10
Load-side droop pulses
(Note 3, 4, 5)
(±10 V/100 pulses)
100 [pulse]
CW direction
CCW direction
100 [pulse]
0
10 [V]
-10 [V]
11
Load-side droop pulses
(Note 3, 4, 5)
(±10 V/1000 pulses)
1000 [pulse]
CW direction
CCW direction
1000 [pulse]
0
10 [V]
-10 [V]
12
Load-side droop pulses
(Note 3, 4, 5)
(±10 V/10000 pulses)
10000 [pulse]
CW direction
CCW direction
10000 [pulse]
0
10 [V]
-10 [V]
13
Load-side droop pulses
(Note 3, 4, 5)
(±10 V/100000 pulses)
100000 [pulse]
CW direction
CCW direction
100000 [pulse]
0
10 [V]
-10 [V]
14
Load-side droop pulses
(Note 3, 4, 5)
(±10 V/1 Mpulse)
1 [Mpulse]
CW direction
CCW direction
1 [Mpulse]
0
10 [V]
-10 [V]
15
Motor-side/load-side
position deviation
(Note 3, 4, 5)
(±10 V/100000 pulses)
100000 [pulse]
CW direction
CCW direction
100000 [pulse]
0
10 [V]
-10 [V]
16
Servo motor-side/load-
side speed deviation
(Note 4)
Maximum speed
CW direction
CCW direction
Maximum speed
0
8 [V]
-8 [V]
17
Internal temperature of
encoder
(±10 V/±128 ˚C)
128 [°C]
-128 [°C]
0
10 [V]
-10 [V]
Note 1.
Encoder pulse unit.
2.
Available in position control mode
3.
This cannot be used in the torque control mode.
4.
This can be used with setup software (MR Configurator2
TM
) with software version 1.19V or later.
5.
This cannot be used in the speed control mode.
8.
For details on the maximum current command (maximum torque) for ±8 V, refer to app. 7.(4) for details.
