Revision history RM0033
1372/1381 RM0033 Rev 9
26-Apr-2018
8
(continued)
SPI
Register for RXONLY changed from SPI_CR2 to SPI_CR1 in
Section 25.3.4: Configuring the SPI for half-duplex communication
and Section : Unidirectional receive-only procedure (BIDIMODE=0
and RXONLY=1).
USB OTG_FS
Replaced bit 18 by bit 19 in OEPINT bit description of
OTG_FS_DAINT and OEPM bit description of
OTG_FS_DAINTMSK.
Updated reset values for OTG_FS Host periodic transmit FIFO size
register (OTG_FS_HPTXFSIZ) and OTG_FS device IN endpoint
transmit FIFO size register (OTG_FS_DIEPTXFx) (x = 1..3, where x
is the FIFO_number).
Updated STALL bit description in OTG_FS device endpoint-x control
register (OTG_FS_DOEPCTLx) (x = 1..3, where x =
Endpoint_number).
USB OTG_HS
Removed I2C interface from the whole document.
Updated Figure 373: USB OTG interface block diagram and added
Table 159: OTG_HS input/output pins.
Added Figure 374: USB host-only connection.
Modified SOF pulse width in Section 30.7.2: Peripheral SOFs.
Added Table 160: Compatibility of STM32 low power modes with the
OTG in Section 30.8: OTG_HS low-power modes.
Updated Figure 377: Interrupt hierarchy.
Updated Table 163: Device-mode control and status registers.
Section : OTG_HS control and status register
(OTG_HS_GOTGCTL): updated reset value and SRQ definition.
Updated Section : OTG_HS USB configuration register
(OTG_HS_GUSBCFG)
Section : OTG_HS reset register (OTG_HS_GRSTCTL): updated
reset value and FCRST definition.
Section : OTG_HS interrupt mask register (OTG_HS_GINTMSK):
changed PRTIM access type to ‘rw’ and suppressed EPMISM bit.
Updated Section : OTG_HS Receive FIFO size register
(OTG_HS_GRXFSIZ) reset value.
Changed NPTXFD access type in Section : OTG_HS nonperiodic
transmit FIFO size/Endpoint 0 transmit FIFO size register
(OTG_HS_GNPTXFSIZ/OTG_HS_TX0FSIZ).
Updated Section : OTG_HS nonperiodic transmit FIFO/queue status
register (OTG_HS_GNPTXSTS) and Section : OTG_HS general
core configuration register (OTG_HS_GCCFG) reset value.
Suppressed OTG_HS_GI2CCTL register
Updated FRIVL definition in Section : OTG_HS Host frame interval
register (OTG_HS_HFIR).
Table 224. Document revision history (continued)
