– Unplug the connectors -1- and -2- and detach the storage
compartment.
– Unplug the connectors -1-.
– Screw out the bolts -arrows- on either side of the centre con‐
sole.
– Press the button -arrow- and take out the front ashtray insert
-1-.
– Screw out the bolt -arrow- and remove the housing for the front
ashtray.
– Unplug the connector.
