– On vehicles with knee airbag: Pull catch -2- in direction of ar‐
row and unplug electrical connectors -1- and -3-.
– Remove glove box.
Vehicles without Climatronic operating and display unit (rear):
– Open ashtray (rear) -2-.
– Detach trim -1- from mounting frame -arrow-.
– Close ashtray.
– Detach ashtray from mounting frame in direction of -arrow-.
Vehicles with Climatronic operating and display unit (rear):
– Prise trim -1- off mounting frame using removal wedge -3409-
-arrow-.
Audi A8 2003 ➤
General body repairs, interior - Edition 07.2011
2. Removing and installing centre console without extension 23
