E4 Series
Maintenance Manual
Electrical Power
E4.08.04
Rev. 29
Page 211
24-30-00
01-Jul-2020
Fig. 24 - 16 ASSY Brush holder E4A-91-300-000
with brushes pushed back in mounting position
Thin Metal Sheet
Push Direction
Cover
Upper Brush Position
Lower Brush Position
Cover Rib
Cover
End Position
Fig. 24 - 15 Brush holder
