E4 Series
Maintenance Manual
Reciprocating
Engine
Page 320
E4.08.04
Rev. 29
85-Maintenance Procedures
01-Jul-2020
B. Replace the Timing Chain and the Camshaft Chain Wheel
The following parts are used to replace the timing chain and the chain wheel:
No.
Part Number
Quantity
Description
01
E4A-75-100-000
1
Timing chain, open version
02
-
1
Chain link, part of Timing chain
03
-
1
Chain clip, part of Timing chain
04
E4A-07-000-402
3
Screws for chain wheel
05
E4A-07-000-101
1
Chain wheel
06
E4A-22-000-803 *)
2
Screws for assy sensor housing
*) interchangeable with E4A-01-000-801, E4A-10-000-803 and E4A-55-100-802
Make sure the special tools are not damaged!
No.
Tool Number
Quantity
Description
01
AEP-00150
1
Timing chain measuring tool
02
AEP-00158
1
Chain opening tool
- Bracket
- Fixing screw
- Screw with opening bolt
03
AEP-00159
1
Chain closing tool
- Bracket
- Chain link positioner
- Positioner screw
- Screw with closing bolt
- Adapter block
04
AEP-00160
1
Chain coupling
05
AEP-00139
1
Chain guiding bar
07
AE300T009
1
Camshaft adjusting tool
Special Tools
