E4 Series
Maintenance Manual
Power Plant
Page 204
E4.08.04
Rev. 29
71 - Maintenance Procedures
01-Jul-2020
71-50-00 Electrical Harness
1. General
This section contains information on maintenance procedures for the engine harness that
connects the power plant system.
2. Maintenance Procedures
Special Tools
Number
Description
Dimensions
1
Crimper
-
2
Gauge
-
3
Insertion/Extraction tool
-
A. Examine the engine wiring harness
Detail Steps/Work Items
Key Items/References
(1)
Examine the engine harness for:
- chafing
- damage
- missing clamps.
Refer to Fig. 71 - 5 and Fig. 71 - 6.
(2)
Make sure that the interlocking of the plug
and socket connections are correct.
e.g. ECU connector or Injector
connector
(3)
If you find wear or damage, replace the
engine wiring harness.
