Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Engine Oil
System
Page 216
E4.08.04
Rev. 29
79-Maintenance Procedures
01-Jul-2020
Detail Steps/Work Items
Key Items/References
(12)
Make sure that the O-Rings at the oil pipe are in
the correct position.
Refer to Fig. 79 - 12.
Do not use Loctite on thread with grease!
Apply only a thin layer of Loctite!
(13)
Apply Loctite 243 on screws.
(14)
Tighten the oil separator.
Torque 5 Nm.
(15)
Install the injector cover.
Refer to Section 85-10-00
Paragraph 3.B.
(16)
Clean the working area.
(17)
Do an engine ground run.
Refer to Section 71-00-01.
(18)
Examine the oil system for leakage.
C. Remove the Oil Separator By-pass Valve
Detail Steps/Work Items
Key Items/References
(1)
Remove the injector cover.
Refer to Section 85-10-00
Paragraph 3.A.
(2)
Remove the oil separator.
Refer to Paragraph A.
(3)
Remove the by-pass valve from the oil separator.
Refer to Fig. 79 - 12.
(4)
Clean and examine the thread.
D. Install the Oil Separator By-pass Valve
Detail Steps/Work Items
Key Items/References
Do not use Loctite on thread with grease!
Apply only a thin layer of Loctite!
(1)
Apply Loctite 243 on the by-pass valve.
(2)
Install the new by-pass valve on the oil
separator.
(3)
Carefully tighten the by-pass valve.
Hand torque.
(4)
Install the oil separator on the injector cover.
Refer to Paragraph B.
(5)
Install the injector cover.
Refer to Section 85-10-00
Paragraph 3.B.
