E4 Series
Maintenance Manual
Engine Oil
System
E4.08.04
Rev. 29
Page 217
79-Maintenance Procedures
01-Jul-2020
Detail Steps/Work Items
Key Items/References
(6)
Clean the working area.
(7)
Do an engine ground run.
Refer to Section 71-00-01.
(8)
Examine the oil system for leakage.
Fig. 79 - 11 Oil separator hose installation
Fig. 79 - 12 Oil separator – exploded view
clamp
Hose 2
O-rings
Oil pipe
by-pass valve
screws
Oil separator
Hose 1
