E4 Series
Maintenance Manual
Reciprocating
Engine
Page 260
E4.08.04
Rev. 29
85-Maintenance Procedures
01-Jul-2020
85-20-00 Reciprocating Engine - Power Section
1. Crankshaft Cover
For removal and installation of the crankshaft cover, remove the engine from the aircraft.
A. Remove the Crankshaft Cover
Detail Steps/Work Items
Key Items/References
(1)
Drain the coolant.
Refer to the applicable Aircraft
Maintenance Manual.
(2)
Drain the engine oil.
Refer to Section 79-20-00 Paragraph
5.A.
(3)
Remove the engine from the aircraft.
Refer to the applicable Aircraft
Maintenance Manual.
(4)
Remove the gearbox.
Refer to Paragraph 4.A.
(5)
Remove the two-mass flywheel.
Refer to Paragraph 5.A.
(6)
Remove the oil sump.
Refer to Section 79-10-00 Paragraph
3.A.
(7)
Remove the 6 screws from the crankshaft
cover.
Refer to Fig. 85 - 89.
(8)
Remove the crankshaft cover.
