Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Reciprocating
Engine
Page 308
E4.08.04
Rev. 29
85-Maintenance Procedures
01-Jul-2020
(k) Install the parts attached to the cylinder head
Detail Steps/Work Items
Key Items/References
For assembly of the A/C installation, refer to the related A/C Maintenance
Manual.
(1)
Install the glow plugs.
Refer to Section 80-10-00
Paragraph 3.C.
(2)
Install the injectors.
Refer to Section 73-10-01
Paragraph B.
(3)
Install the fuel rail.
Refer to Section 73-20-02
Paragraph B.
(4)
Install the high pressure pump (HPP).
Refer to Section 73-10-03
Paragraph B.
(5)
Install the intake air manifold.
Make sure all sensors are
installed.
Refer to Paragraph 1.B.
(6)
Install the exhaust manifold.
Make sure turbocharger is
installed.
Refer to Section 78-10-00
Paragraph 2.B.
(7)
Install the gasket on the turbocharger oil return
line.
Refer to Section 79-20-00
Paragraph 9.B.
(8)
Install the turbocharger oil return line.
(9)
Install the sealing ring on the turbocharger oil
supply line.
Refer to Section 79-20-00
Paragraph 8.B.
(10)
Install the turbocharger oil supply line.
(11)
Install the wiring harness.
Refer to Section 71-50-00.
(12)
Connect all sensors.
(13)
Install the oil return line at the oil separator.
Refer to Section 79-20-00
Paragraph 7.B.
(14)
Install the injector cover.
Refer to Section 85-10-00
Paragraph 3.B.
(15)
Fill the engine with coolant and bleed the cooling
system.
Refer to the applicable Aircraft
Maintenance Manual.
(16)
Do an engine ground run.
Refer to Section 71-00-01.
Make sure you perform the power analysis in the same conditions as the
power analysis before the cylinder head replacement.
(17)
Complete a power analysis:
 Start cold engine, adjust the temperatures to correct operation conditions
(50°C Engine Oil Temp, 60°C Coolant Temp, 35°C Gearbox Oil Temp)
 Start Recording with attached LiveView-Config
 Complete the Self-Test
