Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Reciprocating
Engine
E4.08.04
Rev. 29
Page 223
85-Maintenance Procedures
01-Jul-2020
5. Two-Mass-Flywheel
Install only a hub and a two-mass flywheel approved for your engine
configuration.
If the hub and the two-mass flywheel are marked with serial numbers, the serial
numbers must agree.
If the hub or the two-mass flywheel is unserviceable, always replace the two
components.
Use dry and clean gloves when you work on the two-mass-flywheel.
A. Remove the Two-Mass-Flywheel
Detail Steps/Work Items
Key Items/References
(1)
Remove the engine starter.
Refer to Section 80-10-00 Paragraph
2.A.
(2)
Remove the gearbox.
Refer to Paragraph A.
(3)
Disconnect the ground strip of the crankshaft
sensor connectors.
(4)
Disconnect the crankshaft sensor connectors.
(5)
Remove the crankshaft sensors.
Refer to Section 76-10-00 Paragraph
4.A.
(6)
Attach the flywheel locking tool.
Refer to Fig. 85 - 38.
(7)
Remove the 8 screws from the hub.
Refer to Fig. 85 - 39.
(8)
Remove the hub.
(9)
Remove the 8 screws from the two-mass-
flywheel.
(10)
Remove the two-mass-flywheel.
(11)
Remove the flywheel locking tool.
Refer to Fig. 85 - 38.
(12)
Examine the hole threads.
(13)
Clean the hole threads.
