Austro Engine E4 Series

To Next Page

To Previous Page

E4 Series

Maintenance Manual

Reciprocating

Engine

Page 226

E4.08.04

Rev. 29

85-Maintenance Procedures

01-Jul-2020

Fig. 85 - 39 Two-mass flywheel installation

Fig. 85 - 40 Hub installation

Hub

Screw

Centering pin #1

Centering pin #2

Gently tapping with soft

faced hammer
