Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Reciprocating
Engine
E4.08.04
Rev. 29
Page 201
85-Maintenance Procedures
01-Jul-2020
85-10-00 Reciprocating Engine - Front Section
1. General
This section contains the maintenance procedures for the reciprocating engine front section.
2. Special Tools
Number
Description
Dimensions
1
Spring band clamp pliers
2
Flywheel Locking Tool
3
Soft faced hammer
4
Lever bar (slotted)
Approx. 8mm thick
5
Two-mass flywheel Tester
AEP-0061
6
Hook
7
AEP-00131, AEP-00132
8
AE300T-010, AE300T-009
3. Injector Cover
A. Remove the Injector Cover
Detail Steps/Work Items
Key Items/References
(1)
Remove the lock-wire and the three screws
from the maintenance lid, if installed before.
Refer to Fig. 85 - 6.
(2)
Remove the maintenance lid, if installed
before.
Push the maintenance lid in the
direction of the screw holes.
(3)
Disconnect the breather line from the injector
cover.
Refer to the applicable Aircraft
Maintenance Manual.
(4)
Remove the oil separator return line.
Refer to Section 79-20-00 Paragraph
7.A.
(5)
Remove the screws from the injector cover.
Refer to Fig. 85 - 7.
(6)
Carefully lift up the injector cover.
(7)
Open the oil separator hose clamp.
Refer to Fig. 85 - 9.
(8)
Pull off the oil separator hose from the
cylinder head.
(9)
Remove the injector cover.
