E4 Series
Maintenance Manual
Standard
Procedures
E4.08.04
Rev.29
Page 203
70 - Maintenance Procedures
01-Jul-2020
A. Single wire locking
Detail Steps/Work Items
Key Items/References
Do not use a lock-wire longer than 60 cm for single wire locking three or
more parts as a group!
(1)
Put the wire through each part, one after
other, in the direction that will prevent the part
from loosening.
Refer to Fig. 70 - 2.
(2)
Pull the wire tightly around each bend and
twist the ends into a tight pigtail near one of
the safety wired parts.
(3)
Cut the pigtail square.
Keep a minimum of three twists.
(4)
Bend the pigtail over against the part being
safety wired to prevent it from becoming a
snag.
(5)
Remove the cut-off ends.
Make sure that no debris enters the
engine by any opening.
Fig. 70 - 2 Single wire locking
