Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Power Plant
E4.08.04
Rev. 29
Page 227
71 -Maintenance Procedures
01-Jul-2020
D. Install the engine wiring harness E4A-95-000-000 and E4B-95-000-000
Material and safety elements for the E4A/E4B engine wiring harness installation
Pos
Part Number
Description
QTY
Torque in
Nm
01
E4A(B)-95-000-000
Assy – Engine Harness
1
02
DIN3016-W1-DM28-20
Clamp 28
1
03
DIN3016-W1-DM 22x15
Clamp 22
2
04
DIN3016-W3/W4-DM 8x15
Clamp 8
1
05
PLT4S-M30
Cable Tie
25
06
E4A-90-100-808
Edge Clip
2
07
E4A-90-100-809
Edge Clip
4
08
50266513
Edge Clip
3
09
E4A-90-000-801
Ripp Lock Screw
1
5
10
E4A-95-100-000
Assy – Additional Shielding Fuel
Pressure
1
11
3864b.60 *)
Vogt Blade Terminal BPA
1
12
61365-1 *)
TE Blade Terminal CAS 1
1
13
50251566
Herth + Buss Blade Terminal for
FMU / CTS Pigtail
1
14
Reserved
15
Reserved
*) Only necessary for engine harness revision AD.1 or higher.
