E4 Series
Maintenance Manual
Reciprocating
Engine
E4.08.04
Rev. 29
Page 281
85-Maintenance Procedures
01-Jul-2020
(d) Remove the rear cylinder head cover
Detail Steps/Work Items
Key Items/References
(1)
Remove the screws that attach the rear
cylinder head cover.
Refer to Fig. 85 - 101.
(2)
Remove the rear cylinder head cover and the
O-Ring.
Fig. 85 - 101 Rear cylinder head cover
Cylinder head cover
Screw
Screw
O-Ring
