E4 Series
Maintenance Manual
Engine Oil
System
Page 210
E4.08.04
Rev. 29
79-Maintenance Procedures
01-Jul-2020
Fig. 79 - 8 Oil filter installation
4. Oil Filter Housing Drain Line
A. Remove the Oil Filter Housing Drain Line
Detail Steps/Work Items
Key Items/References
(1)
Open the sleeve nut of the drain line on the
upper end (oil filter housing).
Refer to Fig. 79 - 9.
(2)
Open the sleeve nut of the drain line on the
lower end (oil sump).
(3)
Remove the lock-wire from the banjo bolt at the
oil sump.
(4)
Remove the banjo bolt at the oil sump.
(5)
Carefully remove the drain line.
(6)
Remove the gasket rings from the banjo bolt.
When you loosen or tighten the hose connections which are attached with a
twin nipple, always hold the twin nipple tightly!
Filter cover
Oil filter
