Austro Engine E4 Series

To Next Page

To Previous Page

E4 Series

Maintenance Manual

Engine Oil

System

Page 212

E4.08.04

Rev. 29

79-Maintenance Procedures

01-Jul-2020

Fig. 79 - 9 Oil filter housing drain line installation

Banjo

bolt

Lock-wire

Sleeve

nut

Oil sump

drain line

Sleeve nut

Filter housing
