Austro Engine E4 Series - Install the Starter

E4 Series
Maintenance Manual
Starting
Page 202
E4.08.04
Rev. 29
80 - Maintenance Procedures
01-Jul-2020
B. Install the Starter
Detail Steps/Work Items
Key Items/References
(1)
Carefully put the starter to the crankcase
housing.
Be careful with the ring gear!
Refer to Fig. 80 - 1.
(2)
Put the GPC-bracket in the correct position.
(3)
Tighten the two screws on the starter.
Torque 22 Nm
(4)
Tighten the two screws and the spacer on the
GPC-bracket.
Torque 13 Nm
(5)
Connect the electrical cables to the GPC.
(6)
Attach a new tie rap on the branch of the
GPC.
Refer to Fig. 80 - 1.
(7)
Connect the electrical cables to the starter.
Refer to the applicable Aircraft
Maintenance Manual.
(8)
Connect the battery.
(9)
Do an engine ground run.
Refer to Section 71-00-01.
