Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Power Plant
E4.08.04
Rev. 29
Page 3
71 - System Description
01-Jul-2020
Wiring Harness E4A-90-000-000 Plug Connectors Description
Wiring
diagram
Description long version
German description
Abbr.
B1/1
Fuel Pressure Sensor
Kraftstoffdrucksensor
FPS
B4/6
Rail Pressure Sensor
Raildrucksensor
RPS
B40
Oil Combinant Sensor Temperature
Kombinierter Ölsensor Temperatur
MOK
B5/1
Boost Pressure Sensor 1
Ladedrucksensor
BPS1
B5/2
Boost Pressure Sensor 2
Ladedrucksensor
BPS2
B5/3
Oil Pressure Sensor
Öldrucksensor
OPS
B50/1
Intake Air Temperature 1
Ladelufttemperatursensor
IAT 1
B50/2
Intake Air Temperature 2
Ladelufttemperatursensor
IAT 2
B50/3
Coolant Temperature Sensor
Kühlwassertemperatursensor
CTS
B50/5
Gearbox Temperatur Sensor
Getriebetemperatursensor
GBTS
B50/6
GPC Coolant Temperature
Kühlwassertemperatursensor GPC
CTS_GPC
B50/7
Fuel Temperature Sensor
Kraftstofftemperatursensor
FTS
B6/1
Camshaft Sensor 1
Nockenwellensensor
CAS 1
X)
B6/2
Camshaft Sensor 2
Nockenwellensensor
CAS 2
X)
G115
ECU A
G121
ECU Power
G116
ECU B
G2
Alternator Plug
Alternator Stecker
GEN
GPC
A/C Interface 6
L5/1
Crankshaft Sensor 1
Kurbelwellensensor 1
CRS 1
L5/2
Crankshaft Sensor 2
Kurbelwellensensor 2
CRS 2
M55
Governor Actuator
Governor
GOV
N14/2
Glow Plug Control
GPC Glow Plug Control
GPC
R9/1
Glow Plug 1
Glühkerze 1
GP 1
R9/2
Glow Plug 2
Glühkerze 2
GP 2
R9/3
Glow Plug 3
Glühkerze 3
GP 3
R9/4
Glow Plug 4
Glühkerze 4
GP 4
W11
X1/1
A/C Interface 1
X1/2
A/C Interface 2
X2/1
A/C Interface 3
X3/1
A/C Interface 4
X3/2
A/C Interface 5
Y31/5
Boost Pressure Actuator
EPW
BPA
Y74
Pressure Control Valve
Druckregelventil Rail
PCV
Y76/1
Fuel Injector 1
Injektor
INJ 1
X)
Y76/2
Fuel Injector 2
Injektor
INJ 2
X)
Y76/3
Fuel Injector 3
Injektor
INJ 3
X)
Y76/4
Fuel Injector 4
Injektor
INJ 4
X)
