E4 Series
Maintenance Manual
Power Plant
Page 240
E4.08.04
Rev. 29
71 - Maintenance Procedures
01-Jul-2020
Fig. 71 - 47 Harness branch installation on high pressure rail
Fig. 71 - 48 Pigtail connection for E4A-
95-000-000 rev. AD.1 and lower
Fig. 71 - 49 Pigtail connection for E4B-
95-000-000 rev. AD.1 and lower
Rail
Cable tie[05]
Pigtails BPS1 & IAT 2
Pigtails BPS2 & IAT 2
Pigtails BPS1 & IAT1
Pigtails BPS2 & IAT 2
