Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Power Plant
Page 272
E4.08.04
Rev. 29
71 - Maintenance Procedures
01-Jul-2020
E. Remove the engine wiring harness
Detail Steps/Work Items
Key Items/References
(7)
Disconnect the power source.
(8)
Remove the Injector Cover.
Refer to Section 85-10-00 Paragraph
3.A.
(9)
Remove all clamps.
(10)
Remove the cable tie from the edge clip and
the starter motor.
(11)
Disconnect the shielding cable.
(12)
Disconnect the wiring harness from all
electrical equipment.
First on the gearbox right side.
(13)
Unlock each connector.
Refer to Fig. 71 - 93.
(14)
Disconnect the plugs.
Refer to Fig. 71 - 93.
(15)
Remove the harness.
