E4 Series
Maintenance Manual
Power Plant
Page 314
E4.08.04
Rev. 29
71 - Maintenance Procedures
01-Jul-2020
E4A-95-R17-000
Connector
Pin
Connect
or
Pin
X1/1
25
GPC
23
X1/1
26
GPC
16
X1/1
27
GPC
15
X1/1
28
GPC
9
X1/1
29
GPC
8
X1/1
30
GPC
11
X1/1
31
GPC
17
X1/1
32
GPC
22
W11/1
Ring
Terminal
GPC
19
GPC
12
GP1
1
GPC
7
GP2
1
GPC
6
GP3
1
GPC
3
GP4
1
GPC
2
CTS_GPC
1
GPC
21
CTS_GPC
2
GPC
20
Table 71 - 5
Fig. 71 - 111 Contact insertion
